Modules optiques et d'interface

The NVIDIA 980-9I51S-00NS00 is a single-port OSFP 400GBase-SR4 optical transceiver module designed for high-performance InfiniBand NDR and Ethernet networks. It supports a data rate of 400 Gbps over four 100G-PAM4 lanes and utilizes an 850 nm wavelength for transmission over multimode fiber (MMF). The module features an MPO-12/APC connector and supports distances up to 50 meters. It includes Digital Optical Monitoring (DOM) for real-time diagnostics and complies with industry standards such as IEEE 802.3bs and OSFP MSA.

The NVIDIA 980-9I530-00W000 is a QSFP-DD (Quad Small Form-factor Pluggable Double Density) transceiver module that supports 8x50G PAM4 lanes, providing a total aggregate data rate of 400 Gbps. It utilizes an 850 nm wavelength for transmission over MMF, with a reach of up to 100 meters when using OM4 fiber. The module features an MPO-16 APC connector and supports Digital Optical Monitoring (DOM) for real-time diagnostics

The NVIDIA 980-9I53X-00C000 (MMA1L10-CR) is a QSFP28 100G optical transceiver supporting up to 100 Gb/s data rate over single-mode fiber at 1310 nm wavelength, with up to 40 km reach via LC duplex connector, and full DDMI support.

The NVIDIA 980-9I595-00AM00 is a hot-pluggable SFP28 transceiver module designed for short-range data communication and interconnect applications. It supports both 10G and 25G Ethernet over multimode fiber (MMF) using an 850 nm wavelength. With an LC duplex connector, this module delivers reliable transmission distances of up to 100 meters over OM4 fiber (70 meters over OM3), making it ideal for high-density networking environments such as data centers and enterprise networks. The transceiver complies with IEEE 802.3by (25GBASE-SR), IEEE 802.3ae (10GBASE-SR), and SFF-8472 with Digital Optical Monitoring (DOM) support.

The NVIDIA 980-9I693-00NS00 is a QSFP112 400GBase-SR4 optical transceiver module designed for high-performance InfiniBand NDR and Ethernet networks. It supports a data rate of 400 Gbps over four 100G-PAM4 lanes and utilizes an 850 nm wavelength for transmission over multimode fiber (MMF). The module features an MPO-12/APC connector and supports distances up to 50 meters.

The NVIDIA 980-9I71G-00J000 adapter facilitates the connection of SFP+ modules or cables to QSFP+ ports. This allows a single-lane SFP+ transceiver or cable to connect to a quad-lane QSFP+ port, effectively converting the port to support 10GbE speeds. This solution is particularly useful in data centers and enterprise networks where flexibility and cost-effective upgrades are essential.

The QSA28 adapter facilitates seamless integration between 100GbE QSFP28 ports and 25GbE SFP28 modules or cables. By inserting this adapter into a QSFP28 port, users can connect an SFP28 transceiver or cable, effectively converting the port to support 25GbE speeds. This solution is particularly useful in data centers and enterprise networks where flexibility and cost-effective upgrades are essential.
